Parameter Default Value Range Conversion Index Data Type Array
12-0* IP Settings
12-00 IP Address Assignment 0.0.0.0 0-255 - Unsigned 8 -
12-01 IP Address 0.0.0.0 0-255 - Oct. string 4 -
12-02 Subnet Mask 0.0.0.0 0-255 - Oct. string 4 -
12-03 Default Gateway 0.0.0.0 0-255 - Oct. string 4 -
12-04 DHCP Server 0.0.0.0 0-255 - Oct. string 4 -
12-05 Lease Expires 00:00:00:00 - - Time diff. w/date -
12-06 Name Servers 0.0.0.0 0-255 - Oct. string 4 -
12-07 Domain Name - max. 19 ch. - Visible string 48 -
12-08 Host Name - max. 19 ch. - Visible string 48 -
12-09 Physical Address 00:1B:08:00:00:00 - - Visible string 17 -
12-1* Ethernet Link Parameters
12-10 Link Status [0] No Link [0 - 1] - Unsigned 8 [0-1]
12-11 Link Duration 00:00:00:00 - - Time diff. w/date [0-1]
12-12 Auto Negotiation [1] On [0-1] - Unsigned 8 [0-1]
12-13 Link Speed [0] None [0-2] - Unsigned 8 [0-1]
12-14 Link Duplex [1] Full Duplex [0-1] - Unsigned 8 [0-1]
12-2* Process Data
12-21 Process Data Config Write - - - Unsigned 16 [0-9]
12-22 Process Data Config Read - - - Unsigned 16 [0-9]
12-27 Master Address 0.0.0.0. 0-255 -
Oct. string
[4]
12-28 Store Data Values [0] Off [0-1] - Unsigned 8 -
12-29 Store Always [0] Off [0-1] - Unsigned 8 -
12-4* Modbus TCP
12-40 Status Parameter [0-1]
12-41 Slave Message Count 0
12-42 Slave Exception Message
Count 0
12-8* Other Ethernet Services
12-80 FTP Server [0] Disable [0-1] - Unsigned 8 -
12-81 HTTP Server [0] Disable [0-1] - Unsigned 8 -
12-82 SMTP Service [0] Disable [0-1] - Unsigned 8 -
12-89 Transparent Socket Channel
Port [0] Disable [0-1] - Unsigned 8 -
12-9* Advanced Ethernet Settings
12-90 Cable Diagnostic [0] Disable [0-1] - Unsigned 8 -
12-91 Auto Cross Over [0] Enable [0-1] - Unsigned 8 -
12-92 IGMP Snooping [0] Enable [0-1] - Unsigned 8 -
12-93 Cable Error Length 0 0-200 0 Unsigned 16 [0-1]
12-94 Broadcast Storm Protection 0 Off-20% - Unsigned 16 [0-1]
12-95 Broadcast Storm Filter [1] Enable [0-1] - Unsigned 8 [0-1]
12-98 Interface Counters 0 0-65535 - Unsigned 16 [0-10]
12-99 Media Counters 0 0 - 65535 - Unsigned 16 [0-11]
Table 5.3 Parameter Group 12-**
Parameters MCA 122 Modbus TCP
MG90P202 - VLT
®
is a protected Danfoss trademark 35
