5.4 Data Types
5.4.1 Data Types Supported by FC 102/FC
202/FC 302
The number to the left refers to a conversion figure, the
one on the right to be used when writing or reading
parameters.
Conversion index Conversion factor
67 1/60
6 1000000
5 100000
4 10000
3 1000
2 100
1 10
0 1
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
-5 0.00001
-6 0.000001
Table 5.4 Conversion Index
