Error
No. Description
Led Indications
Reason Action LED1 LED2 LED3 LED4
119 External error:
Safe fieldbus
destination
address
mismatch.
Reaction: STO.
Destination address on
the safe fieldbus is
invalid.
Make sure that the addresses
of the PLC and the safety
option match.
Status of LED 1 and LED2
depends on safety function
state assigned to DI1 and
DI2.
Red flashing
(500 ms on/
off).
Red flashing
(500 ms on/
off).
120 External error:
Safe fieldbus
telegram
mismatch.
Reaction: STO.
Safe fieldbus telegram
is invalid.
Check the telegram format
settings in the safe PLC and
the safety option.
Red flashing
(500 ms on/
off).
Red flashing
(500 ms on/
off).
121 External error:
PROFIsafe
configuration
error. Reaction:
STO.
PROFIsafe configuration
is invalid.
Check the settings of the
safety option and the PLC.
Red flashing
(500 ms on/
off).
Red flashing
(500 ms on/
off).
9.4 LCP Messages
Any errors on the safety option are indicated on the
frequency converter.
The following options are available for detailed diagnostics
and error detection:
•
LEDs on the front of the safety option provide
information on operating states. The LEDs are
used to indicate the status of the option, i.e.
active safety functions, failures and warnings, if
any.
•
LCP text or info via bus display the status of the
safety functions (for example STO).
The following messages are displayed in online mode in
the MCT 10 Set-up Software:
•
Status of the safety option.
•
Internal and external errors and the
corresponding troubleshooting tips.
To configure the LCP to show the safety option specific
information, use the parameters in parameter group 0-2*
LCP Display.
0-20 Display Line 1.1 Small, 0-21 Display Line 1.2 Small, and
0-22 Display Line 1.3 Small have the following options:
•
42-82 Safe Control Word.
•
42-83 Safe Status Word.
•
42-85 Active Safe Func.
0-23 Display Line 2 Large, 0-24 Display Line 3 Large have the
following options:
•
42-82 Safe Control Word.
•
42-83 Safe Status Word.
•
42-86 Safe Option Info.
9.4.1 LCP Status Messages
This section describes the LCP status messages related to
the safety option. The set of messages is different
depending on whether or not a safe fieldbus is enabled.
Table 9.2 contains messages that are shown regardless of
the safe fieldbus state. Table 9.3 contains messages that
are shown only when the safe fieldbus is disabled.
LCP Message Description
Status
0.0 Hz
50.0 %
!1(1)
0 RPM 0.00 A 0.00KW
!Safe Stop [W68]
Auto Remote Coast
130BE090.10
The safety function was
activated via a digital input or
PROFIsafe.
Status
Safe Func. Pending
SO RESET required!
!1(1)
0 RPM 0.00 A 0.00KW
!Safe Stop [W68]
Auto Remote SO Req. RESET
130BE091.10
The source that triggered the
safety condition has ceased,
but the safety option is
waiting for the reset signal to
continue normal operation.
The LCP shows this message
only if the manual restart
behaviour is selected for the
digital input.
The LCP does not show this
message when the PROFIsafe
control word activates the
safety function, since the
PROFIsafe configuration uses
automatic restart behaviour.
Maintenance, Diagnostics an... Safety Option MCB 152
40 Danfoss A/S © 10/2014 All rights reserved. MG37F102
