3.1.1 MCD5-0021B - MCD5-0053B (G1B)
177HA536.10
1 3
4
5 6
7 9
10
2
8
1Cover 6 Model PCB
2 Cable guide 7 Current transformers
3 Main plastic 8 Mounting posts
4 Terminal blocks 9 SCRs
5 LCP and Main Control PCB 10 Side plastic
3 Service Instructions MCD 500 Service Manual
14
MG.17.L1.02 - VLT
®
is a registered Danfoss trademark
3
