4.8 Current Transformers
Each soft starter requires three current transformers.
MCD5-0021B
175G5649
MCD5-0037B
MCD5-0043B
MCD5-0053B
MCD5-0068B
MCD5-0084B
MCD5-0089B
MCD5-0105B
MCD5-0131B
175G5650
MCD5-0141B
MCD5-0195B
MCD5-0215B
MCD5-0245C 175G5650
MCD5-0360C 175G5652
MCD5-0380C
175G5653
MCD5-0428C
MCD5-0595C
175G5654
MCD5-0619C
MCD5-0790C 175G5655
MCD5-0927C 175G5656
MCD5-1200C 175G5657
MCD5-1410C 175G5658
MCD5-1600C 175G5659
175G5649 - 175G5650 175G5652 - 175G5659
MCD 500 Service Manual 4 Spare Parts
