3.1.4 MCD5-0245C (G3C)
1
2 4
7 9
10
3 5 6
8
11
177HA539.10
1Cover 7Support plastic
2 Cable guide 8 Model PCB
3 Main plastic 9 Current transformers
4 Terminal blocks 10 SCRs
5 LCP and Main Control PCB 11 Main body
6 Fan assembly
MCD 500 Service Manual 3 Service Instructions
MG.17.L1.02 - VLT
®
is a registered Danfoss trademark
17
3
