8.5.2 F3 Terminal Dimensions
Power cables are heavy and hard to bend. To ensure easy installation of the cables, consider the optimum placement of the
drive. Each terminal allows up to 4 cables with cable lugs or a standard box lug. Ground is connected to a relevant
termination point in the drive.
2
295 (11.6)
220 (18.6)
0.0
130BF586.10
154 (6.1) 150 (5.9)
75 (3.0)
439 (17.3) 364 (14.3) 344 (13.5)
1
1 Mains terminals 2 Ground bar
Illustration 8.35 Terminal Dimensions for F3–F4 Options Cabinet, Front View
Exterior and Terminal Dimen... Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 99
8 8
