8.12 F13 Exterior and Terminal Dimensions
8.12.1 F13 Exterior Dimensions
130BF337.10
2280
(89.7)
2204
(86.8)
2800 (110.2)
606
(23.9)
579
(22.8)
624
(24.6)
776
(30.6)
776
(30.6)
Illustration 8.86 Front, Side, and Door Clearance Dimensions for F13
