10.6.3 Mains Contactors, F3–F4
Enclosure size Model and voltage Contactor
F3 P450–P500, 380–480 V
P630–P800, 525–690 V
Eaton XTCE650N22A
F3 P560, 380–480 V Eaton XTCE820N22A
F3 P630. 380–480 V Eaton XTCEC14P22B
F4 P900. 525–690 V Eaton XTCE820N22A
F4 P710–P800. 380–480 V
P1M2, 525–690 V
Eaton XTCEC14P22B
Table 10.31 Mains Contactors, Enclosures F3–F4
NOTICE
Customer-supplied 230 V supply is required for mains contactors.
10.7 Motor
Any 3-phase asynchronous standard motor can be used with a drive.
Terminal Function
96 U/T1
97 V/T2
98 W/T3
99 Ground
Table 10.32 Motor Cable Terminals Providing Clockwise Rotation (Factory Default)
The direction of rotation can be changed by switching 2 phases in the motor cable, or by changing the setting of
parameter 4-10 Motor Speed Direction.
Motor rotation check can be performed using parameter 1-28 Motor Rotation Check and following the
conguration shown in
Illustration 10.18.
Electrical Installation Con... Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 183
10 10
