Danfoss Metasys N2 Design Guide

13 How to Order a Drive
13.1 Drive Congurator
F C - T
130BC530.10
X S A B CX X X X
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 302221 23 272524 26 28 29 31 373635343332 38 39
X D
Table 13.1 Type Code String
Product group
1–6
Model
7–10
Mains Voltage
11–12
Enclosure
13–15
Hardware conguration
16–23
RFI lter/low harmonic drive/
12-pulse
16–17
Brake
18
Display (LCP)
19
PCB coating
20
Mains option
21
Adaptation A
22
Adaptation B
23
Software release
24–27
Software language
28
A options
29–30
B options
31–32
C0 options, MCO
33–34
C1 options
35
C option software
36–37
D options
38–39
Table 13.2 Type Code Example for Ordering a Drive
Congure the correct drive for the proper application by
using the internet-based drive congurator. The drive
congurator is found on the global internet site:
www.danfoss.com/drives. The congurator creates a type
code string and an 8-digit sales number, which can be
delivered to the local sales oce. It is also possible to
build a project list with several products and send it to a
Danfoss sales representative.
An example of a type code string is:
FC-102P450T5E54H4CGCXXXSXXXXA0BXCXXXXD0
The meaning of the characters in the string is
dened in
this chapter. In the example above, an F3 drive is
congured with the following options:
•
RFI lter
•
Safe Torque O with Pilz relay
•
Coated PCB
•
PROFIBUS DP-V1
Drives are delivered automatically with a language package
relevant to the region from which they are ordered. Four
regional language packages cover the following languages:
Language package 1
English, German, French, Danish, Dutch, Spanish, Swedish,
Italian, and Finnish.
Language package 2
English, German, Chinese, Korean, Japanese, Thai,
Traditional Chinese, and Bahasa Indonesian.
Language package 3
English, German, Slovenian, Bulgarian, Serbian, Romanian,
Hungarian, Czech, and Russian.
Language package 4
English, German, Spanish, English US, Greek, Brazilian
Portuguese, Turkish, and Polish.
To order drives with a
dierent language package, contact
the local Danfoss sales oce.
How to Order a Drive
VLT
®
HVAC Drive FC 102
216 Danfoss A/S © 11/2017 All rights reserved. MG16C302
1313
