13.1.1 Ordering Type Code for Enclosures E1–E2
Description Pos Possible option
Product group 1–6 FC-102
Model 8–10 P355–P630
Mains voltage 11–12 T4: 380–480 V AC
T7: 525–690 V AC
Enclosure 13–15 E00: IP00 (chassis - for installation in an external enclosure)
C00: IP00/Chassis with stainless steel back channel
E21: IP21 (NEMA 1)
E54: IP54 (NEMA 12)
E2M: IP21 (NEMA 1) with mains shield
E5M: IP54 (NEMA 12) with mains shield
RFI lter 16–17 H2: RFI lter, class A2 (standard)
H4: RFI lter class A1
1)
B2: 12-pulse drive with RFI lter, class A2
B4: 12-pulse drive with RFI lter, class A1
N2: LHD with RFI lter, class A2
N4: LHD with RFI lter, class A1
Brake 18 B: Brake IGBT mounted
X: No brake IGBT
R: Regen terminals
S: Brake + regen
Display 19 G: Graphical local control panel LCP
N: Numerical local control panel (LCP)
X: No local control panel
PCB coating 20 C: Coated PCB
Mains option 21 X: No mains option
3: Mains disconnect and fuse
5: Mains disconnect, fuse, and load sharing
7: Fuse
A: Fuse and load sharing
D: Load sharing
Adaptation 22 X: Standard cable entries
Adaptation 23 X: No adaptation
Software release 24–27 Actual software
Software language 28 X: Standard language pack
Table 13.3 Ordering Type Code for Enclosures E1–E2
2)
1) Available for 380–480 V only.
2) Consult the factory for applications requiring maritime
certication.
How to Order a Drive Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 217
13 13
