Danfoss Metasys N2 Design Guide

210 (8.3)
0.0
66 (2.6)
181 (7.1)
296 (11.7) 431 (17.0) 546 (21.5) 661 (26.0) 796 (31.3) 911 (35.8)
1026 (40.4)
246 (9.7)
294 (11.6) 330 (13.0) 575 (22.6) 611 (24.0) 659 (25.9) 695 (27.4) 939 (37.0) 975 (38.4)
1023 (40.3) 1059 (41.7)
144 (5.7) 219 (8.6)
512 (20.2) 587 (23.1) 880 (34.7) 955 (37.6)
3
130BF363.10
1
2
1 Brake terminals 3 Ground bar
2 Motor terminals – –
Illustration 8.92 Terminal Dimensions for F12–F13 Inverter Cabinet, Front View
Exterior and Terminal Dimen...
VLT
®
HVAC Drive FC 102
156 Danfoss A/S © 11/2017 All rights reserved. MG16C302
