10.5.1 Power/semiconductor Fuse Options
Model Recommended drive
external fuse
Bussmann PN
Rating Drive internal
option
Bussmann PN
Alternate external
Siba PN
Alternate external
Ferraz Shawmut PN
P315 170M6013 900 A, 700 V 170M6013 22 610 32.900 6.9URD33D08A0900
P355 170M6013 900 A, 700 V 170M6013 22 610 32.900 6.9URD33D08A0900
P400 170M6013 900 A, 700 V 170M6013 22 610 32.900 6.9URD33D08A0900
Table 10.12 380–480 V, Enclosure E, Mains Fuse Options for UL Compliance
Model Recommended drive
external fuse
Bussmann PN
Rating Drive internal option
Bussmann PN
Alternate Siba PN
P450 170M7081 1600 A, 700 V 170M7082 20 695 32.1600
P500 170M7081 1600 A, 700 V 170M7082 20 695 32.1600
P560 170M7082 2000 A, 700 V 170M7082 20 695 32.2000
P630 170M7082 2000 A, 700 V 170M7082 20 695 32.2000
P710 170M7083 2500 A, 700 V 170M7083 20 695 32.2500
P800 170M7083 2500 A, 700 V 170M7083 20 695 32.2500
Table 10.13 380–480 V, Enclosure F, Mains Fuse Options for UL Compliance
Model Drive internal Bussmann PN Rating Alternate Siba PN
P450 170M8611 1100 A, 1000 V 20 781 32.1000
P500 170M8611 1100 A, 1000 V 20 781 32.1000
P560 170M6467 1400 A, 700 V 20 681 32.1400
P630 170M6467 1400 A, 700 V 20 681 32.1400
P710 170M8611 1100 A, 1000 V 20 781 32.1000
P800 170M6467 1400 A, 700 V 20 681 32.1400
Table 10.14 380-480 V, Enclosure F, Inverter Module DC Link Fuses
NOTICE
For UL Compliance, the Bussmann 170M series fuses must be used for units supplied without a contactor-only option.
For units supplied with a contactor-only option, see Table 10.31 for SCCR ratings and UL fuse criteria.
Model Recommended drive
external fuse
Bussmann PN
Rating Drive internal
option
Bussmann PN
Alternate external
Siba PN
Alternate external
Ferraz Shawmut PN
P355 170M4017 700 A, 700 V 170M4017 20 610 32.700 6.9URD31D08A0700
P400 170M4017 700 A, 700 V 170M4017 20 610 32.700 6.9URD31D08A0700
P500 170M6013 900 A, 700 V 170M6013 22 610 32.900 6.9URD33D08A0900
P560 170M6013 900 A, 700 V 170M6013 22 610 32.900 6.9URD33D08A0900
Table 10.15 525–690 V, Enclosure E, Mains Fuse Options for UL Compliance
Electrical Installation Con...
VLT
®
HVAC Drive FC 102
178 Danfoss A/S © 11/2017 All rights reserved. MG16C302
