Enclosure size F8 F9 F10 F11 F12 F13
Power rating
1)
Output at 690 V (kW) 450–630 450–630 710–900 710–900 1000–1400 1000–1400
Output at 575 V (hp) 450–650 450–650 750–1050 750–1050 1150–1550 1150–1550
Front-end conguration
6-pulse – – – – – –
12-pulse S S S S S S
Protection rating
IP IP21/54 IP21/54 IP21/54 IP21/54 IP21/54 IP21/54
NEMA Type 1/12 Type 1/12 Type 1/12 Type 1/12 Type 1/12 Type 1/12
Hardware options
2)
Stainless steel back channel – – – – – –
Mains shielding – – – – – –
Space heater and thermostat – – O O O O
Cabinet light with power
outlet
– – O O O O
RFI lter (Class A1) – O – – O O
NAMUR terminals – – – – – –
Insulation resistance monitor
(IRM)
– O – – O O
Residual current monitor
(RCM)
– O – – O O
Brake chopper (IGBTs) O O O O O O
Safe Torque O O O O O O O
Regen terminals – – – – – –
Common motor terminals – – O O O O
Emergency stop with Pilz
safety relay
– – – – – –
Safe Torque O with Pilz
safety relay
O O O O O O
No LCP – – – – – –
Graphical LCP S S S S S S
Numerical LCP – – – – – –
Fuses O O O O O O
Load share terminals – – – – – –
Fuses + load share terminals – – – – – –
Disconnect – O O O O O
Circuit breakers – – – – – –
Contactors – – – – – –
Manual motor starters – – O O O O
30 A, fuse-protected terminals – – O O O O
24 V DC supply (SMPS, 5 A) O O O O O O
External temperature
monitoring
– – O O O O
Dimensions
Height, mm (in) 2204 (86.8) 2204 (86.8) 2204 (86.8) 2204 (86.8) 2204 (86.8) 2204 (86.8)
Width, mm (in) 800 (31.5) 1400 (55.1) 1600 (63.0) 2400 (94.5) 2000 (78.7) 2800 (110.2)
Depth, mm (in) 606 (23.9) 606 (23.9) 606 (23.9) 606 (23.9) 606 (23.9) 606 (23.9)
Weight, kg (lb) 447 (985.5) 669 (1474.9) 893 (1968.8) 1116 (2460.4) 1037 (2286.4) 1259 (2775.7)
Table 4.8 F8–F13 Drives, 525–690 V
1) All power ratings are taken at normal overload. Output is measured at 690 V (kW) and 575 V (hp).
2) S = standard, O = optional, and a dash indicates that the option is unavailable.
Product Overview
VLT
®
HVAC Drive FC 102
18 Danfoss A/S © 11/2017 All rights reserved. MG16C302
