Danfoss Metasys N2 Design Guide

Type Description Ordering number
IP20 conversion, E2 Provides the drive with an ingress protection rating of IP20/Protected
Chassis. Only for E2 enclosure. 176F1884
Back-channel cooling kits
In back/out back, E1 Allows the cooling air to be directed in and out through the back of
the drive. Kit includes top and base covers for an E1 with protection
rating of IP21/54 (Type1/12).
176F1946
In back/out back, E2 Allows the cooling air to be directed in and out through the back of
the drive. Kit includes top and base covers for an E2 with a protection
rating of IP00 (Chassis).
Welded enclosure – 176F1861
Rittal enclosure – 176F1783
In back/out back, F1–F13 Allows the cooling air to be directed in and out through the back of
the drive. Plates are already included on drive. Contact factory for
installation instructions.
Contact factory
In bottom/out top, E2 Allows the cooling air to be directed in through the bottom and out
through the top of the drive. This kit used only for enclosure E2.
2000 mm (78.7 in) cabinet –
176F1850
2200 mm (86.6 in) cabinet –
176F0299
Out top, E2 Allows the cooling air to be directed out through the top of the drive.
This kit used only for enclosure E2.
176F1776
LCP
LCP 101 Numerical local control panel (NLCP) 130B1124
LCP 102 Graphical local control panel (GLCP) 130B1107
LCP cable Separate LCP cable, 3 m (9 ft) 175Z0929
LCP kit, IP21 Panel mounting kit including graphical LCP, fasteners, 3 m (9 ft) cable,
and gasket
130B1113
LCP kit, IP21 Panel mounting kit including numerical LCP, fasteners, and gasket 130B1114
LCP kit, IP21 Panel mounting kit for all LCPs including fasteners, 3 m (9 ft) cable,
and gasket
130B1117
Table 13.8 Kits Available for Enclosures E1–E2 and F1–F13
13.2.4 Ordering Numbers for A Options: Fieldbuses
Description Ordering number
Uncoated Coated
VLT
®
PROFIBUS DP MCA 101
130B1100 130B1200
VLT
®
DeviceNet MCA 104
130B1102 130B1202
VLT
®
LonWorks MCA 108
130B1106 130B1206
VLT
®
BACnet MCA 109
130B1144 130B1244
VLT
®
PROFINET MCA 120
130B1135 130B1235
VLT
®
EtherNet/IP MCA 121
130B1119 130B1219
VLT
®
Modbus TCP MCA 122
130B1196 130B1296
VLT
®
Powerlink MCA 123
130B1489 130B1490
VLT
®
VACnet/IP MCA 125
– 130B1586
Table 13.9 Ordering Numbers for A Options
For information on eldbus and application option compatibility with older software versions, contact the Danfoss supplier.
How to Order a Drive
VLT
®
HVAC Drive FC 102
222 Danfoss A/S © 11/2017 All rights reserved. MG16C302
1313
