Danfoss Metasys N2 Design Guide

VLT
®
HVAC Drive FC 102
P500 P560 P630 P710
Normal overload NO NO NO NO
(Normal overload=110% current during 60 s)
Typical shaft output at 400 V [kW] 500 560 630 710
Typical shaft output at 460 V [hp] 650 750 900 1000
Typical shaft output at 480 V [kW] 560 630 710 800
Enclosure size F10/F11 F10/F11 F10/F11 F10/F11
Output current (3-phase)
Continuous (at 400 V) [A] 880 990 1120 1260
Intermittent (60 s overload) (at 400 V) [A] 968 1089 1232 1386
Continuous (at 460/480 V) [A] 780 890 1050 1160
Intermittent (60 s overload) (at 460/480 V) [A] 858 979 1155 1276
Continuous kVA (at 400 V) [kVA] 610 686 776 873
Continuous kVA (at 460 V) [kVA] 621 709 837 924
Continuous kVA (at 480 V) [kVA] 675 771 909 1005
Maximum input current
Continuous (at 400 V) [A] 848 954 1079 1214
Continuous (at 460/480 V) [A] 752 858 1012 1118
Maximum number and size of cables per phase
- Motor [mm
2
(AWG)]
8x150 (8x300
mcm)
8x150 (8x300
mcm)
8x150 (8x300
mcm)
8x150 (8x300
mcm)
- Mains [mm
2
(AWG)]
6x120 (6x250
mcm)
6x120 (6x250
mcm)
6x120 (6x250
mcm)
6x120 (6x250
mcm)
- Brake [mm
2
(AWG)]
4x185 (4x350
mcm)
4x185 (4x350
mcm)
4x185 (4x350
mcm)
4x185 (4x350
mcm)
Maximum external mains fuses [A]
1)
900 900 900 1500
Estimated power loss at 400 V [W]
2), 3)
10647 12338 13201 15436
Estimated power loss at 460 V [W]
2), 3)
9414 11006 12353 14041
Maximum added losses A1 RFI, circuit breaker or disconnect, and
contactor [W], (F11 only)
963 1054 1093 1230
Maximum panel options losses [W] 400 400 400 400
Eciency
3)
0.98 0.98 0.98 0.98
Output frequency [Hz] 0–590 0–590 0–590 0–590
Control card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185) 85 (185)
Table 7.5 Electrical Data for Enclosures F10/F11, Mains Supply 6x380–480 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within ± 15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.5 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 10.12 Eciency. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
Specications
VLT
®
HVAC Drive FC 102
52 Danfoss A/S © 11/2017 All rights reserved. MG16C302
77
