PVES Series 4 PVEA Series 4 PVEH Series 4
The PVES has an ASIC closed loop
circuit and the NC-S solenoids.
The PVEA has an ASIC closed loop
circuit, standard NC solenoids
and orifice instead of NO
solenoids.
Caution
PVEA is not for use on PVG 100.
The PVEH has an ASIC closed
loop circuit and the standard NC
solenoids.
PVE hysteresis overview
PVE S A H M
Maximum 2 % 6 % 6 % 35 %
Typical <½ % 2 % 4 % 25 %
•
PVEP has the PVES characteristic.
•
PVEU is available with both standard PVEH and super fine PVES characteristic.
•
PVHC has hysteresis like PVEM at fixed temperature and viscosity. (For PVHC temperature and
viscosity shifts control signal effect.)
Example of PVE use
Signal leads must not act as supply leads at the same time unless the distance between the actuator
module PVE and terminal board is less than 3 m [3.3 yards] and the lead cross-section is min. 0.75 mm
2
[AWG 18].
Technical Information
PVE, Series 4 for PVG 32/100/120 and PVHC
PVE control
32 520L0553 • Rev GD • Jan 2014
