Danfoss PVE Series 4 User Manual

AMP with separate float pin Deutsch version with separate float pin
LED
Float
Not con-
nected
Error
157-779
Float
Error
U
s
3
2
1
4
5
6
No con-
nection
PVEH-F
U
DC
LED
PVEP with controled PWM
PVEP connection
Connector PWM A Error PWM B Gnd U
DC
Deutsch p 1 p 2 p 3 p 5 p 6
Control (U
S
) for standard mounted PVEP
Function Voltage relative PWM
Neutral < 10% < 10%
Q: P → A 10% → 80% < 10%
Q: P → B < 10% 10% → 80%
Deutsch version with PVEP
LED
Technical Information PVE, Series 4 for PVG 32/100/120 and PVHC
Technical Data
46 520L0553 • Rev GD • Jan 2014
