Danfoss VLT 6000 HVAC User Manual

VLT
®
6000 HVAC
107MG.60.B1.02 - VLT is a registered Danfoss trade mark
★ = factory setting. ( ) = display text [ ] = value for use in communication via serial communication port
Programming
323 Relay 1, output function
(RELAY1 FUNCTION)
Function:
This output activates a relay switch.
Relay switch 01 can be used for bringing status and
warnings. The relay is activated when the conditions
for the relevant data values have been fulfilled.
Activation/deactivation can be programmed in
parameter 324 Relay 1, ON delay and parameter 325
Relay 1, OFF delay.
See technical data page 43.
Description of choice:
See data choice and connections on page 106.
324 Relay 01, ON delay
(RELAY1 ON DELAY)
Value:
0 - 600 sec. ★ 0 sec.
Function:
This parameter allows a delay of the cut-in time of
relay 1 (terminals 1-2).
Description of choice:
Enter the desired value.
325 Relay 01, OFF delay
(RELAY1 OFF DELAY)
Value:
0 - 600 sec. ★ 0 sec.
Function:
This parameter makes it possible to delay the cut-out
time of relay 01 (terminals 1-2).
Description of choice:
Enter the desired value.
326 Relay 2, output function
(RELAY2 FUNCTION)
Value:
See functions of relay 2 on previous page.
Function:
This output activates a relay switch.
Relay switch 2 can be used for bringing status and
warnings. The relay is activated when the conditions
for the relevant data values have been fulfilled.
See technical data, page 43.
Description of choice:
See data choice and connections on page 106.
327 Pulse reference, max. frequency
(PULSE REF. MAX)
Value:
100 - 65000 Hz at terminal 29 ★ 5000 Hz
100 - 5000 Hz at terminal 17
Function:
This parameter is used to set the pulse value that
must correspond to the maximum reference,
parameter 205 Maximum reference, Ref
MAX
.
The pulse reference signal can be connected via
terminal 17 or 29.
Description of choice:
Set the required maximum pulse reference.
328 Pulse feedback, max. frequency
(PULSE FDBK MAX.)
Value:
100 - 65000 Hz at terminal 33 ★ 25000 Hz
Function:
This is where the pulse value that must correspond to
the maximum feedback value is set. The pulse
fedback signal is connected via terminal 33.
Description of choice:
Set the desired feedback value.
