VLT
®
6000 HVAC
150
MG.60.B1.02 - VLT is a registered Danfoss trade mark
■■
■■
■ List of warnings and alarms
The table gives the different warnings and alarms and
indicates whether the fault locks the VLT frequency
converter. After Trip locked, the mains supply must be
cut and the fault must be corrected. Reconnect the
mains supply and reset the VLT frequency converter
before being ready. A Trip can be reset manually in
three ways
1) Via the control key [RESET]
2) Via a digital input
3) Via serial communication
In addition, an automatic reset may be selected in
parameter 400 Reset function.
Wherever a cross is placed under both Warning and
Alarm, this can mean that a warning precedes the
alarm. It can also mean that it is possible to program
whether a given fault is to result in a warning or an
alarm. This is possible, e.g. in parameter 117 Motor
thermal protection. After a trip, the motor will be
coasting and on the VLT frequency converter alarm
and warning will flash. If the fault is removed, only the
alarm will flash. After a reset, the VLT frequency
converter will be ready to start operation again.
No. Description Warning Alarm Trip locked Help
1 10 Volts low (10 VOLT LOW) X Page 151
2 Live zero fault (LIVE ZERO ERROR) X X Page 151
4 Mains phase fault (MAINS PHASE LOSS) X X X Page 151
5 Voltage warning high (DC LINK VOLTAGE HIGH) X Page 151
6 Voltage warning low (DC LINK VOLTAGE LOW) X Page 151
7 Overvoltage (DC LINK OVERVOLT) X X Page 151
8 Undervoltage (DC LINK UNDERVOLT) X X Page 152
9 Inverter overloaded (INVERTER TIME) X X Page 152
10 Motor overloaded (MOTOR TIME) X X Page 152
11 Motor thermistor (MOTOR THERMISTOR) X X Page 152
12 Current limit (CURRENT LIMIT) X X Page 152
13 Overcurrent (OVERCURRENT) X X Page 152
14 Earth fault (EARTH FAULT) X X Page 152
15 Switch mode fault (SWITCH MODE FAULT) X X Page 152
16 Short-circuit (CURR.SHORT CIRCUIT) X X Page 152
17 Serial communication timeout (STD BUSTIMEOUT) X X Page 152
18 HPFB bus timeout (HPFB TIMEOUT) X X Page 152
19 Fault in EEprom on power card (EE ERROR POWER) X Page 153
20 Fault in EEprom on control card (EE ERROR CONTROL) X Page 153
22 Auto-optimisation not OK (AMA FAULT) X Page 153
29 Heat-sink temperature too high (HEAT SINK OVERTEMP.) X X Page 154
30 Motor phase U missing (MISSING MOT.PHASE U) X Page 154
31 Motor phase V missing (MISSING MOT.PHASE V) X Page 154
32 Motor phase W missing (MISSING MOT.PHASE W) X Page 154
34 HBFB communication fault (HBFB COMM. FAULT) X X Page 154
35 Out of frequency range (OUT FREQ RNG/ROT LIM) X Page 154
37 Inverter fault (GATE DRIVE FAULT) X X Page 154
39 Check parameters 104 and 106 (CHECK P.104 & P.106) X Page 154
40 Check parameters 103 and 105 (CHECK P.103 & P.105) X Page 154
41 Motor too big (MOTOR TOO BIG) X Page 155
42 Motor too small (MOTOR TOO SMALL) X Page 155
60 Safety stop (EXTERNAL FAULT) X Page 155
61 Output frequency low (FOUT < FLOW) X Page 155
62 Output frequency high (FOUT > FHIGH) X Page 155
63 Output current low (I MOTOR < I LOW) X X Page 155
64 Output current high (I MOTOR > I HIGH) X Page 155
65 Feedback low (FEEDBACK < FDB LOW) X Page 155
66 Feedback high (FEEDBACK > FDB HIGH) X Page 155
67 Reference low (REF. < REF. LOW) X Page 155
68 Reference high (REF. > REF. HIGH) X Page 155
99 Unknown fault (UNKNOWN ALARM) X X Page 155
