VLT
®
6000 HVAC
46
MG.60.B1.02 - VLT is a registered Danfoss trade mark
VLVL
VLVL
VL
T typeT type
T typeT type
T type
60026002
60026002
6002
60036003
60036003
6003
60046004
60046004
6004
60056005
60056005
6005
60066006
60066006
6006
60086008
60086008
6008
60116011
60116011
6011
Output current I
VLT,N
[A] (380-415 V) 3.0 4.1 5.6 7.2 10.0 13.0 16.0
I
VLT, MAX
(60 s) [A] (380-415 V) 3.3 4.5 6.2 7.9 11.0 14.3 17.6
I
VLT,N
[A] (440-460 V) 3.0 3.4 4.8 6.3 8.2 11.0 14.0
I
VLT, MAX
(60 s) [A] (440-460 V) 3.3 3.7 5.3 6.9 9.0 12.1 15.4
Output S
VLT,N
[kVA] (400 V) 2.2 2.9 4.0 5.2 7.2 9.3 11.5
S
VLT,N
[kVA] (460 V) 2.4 2.7 3.8 5.0 6.5 8.8 11.2
Typical shaft output P
VLT,N
[kW] 1.1 1.5 2.2 3.0 4.0 5.5 7.5
Typical shaft output P
VLT,N
[HP] 1.5 2 3 - 5 7.5 10
Max. cable cross-section
to motor [mm
2
/AWG] 4/10 4/10 4/10 4/10 4/10 4/10 4/10
Max. input current I
L,N
[A] (380 V) 2.8 3.8 5.3 7.0 9.1 12.2 15.0
I
L,N
[A] (460 V) 2.5 3.4 4.8 6.0 8.3 10.6 14.0
Max. cable cross-section,
power [mm
2
]/[AWG]
2 )
4/10 4/10 4/10 4/10 4/10 4/10 4/10
Max. pre-fuses [A]/UL
1 )
[A] 16/6 16/10 16/10 16/15 25/20 25/25 35/30
Mains contactor [Danfoss type] CI 6 CI 6 CI 6 CI 9 CI 12 CI 5 CI 6
[AC value] AC-3 AC-3 AC-3 AC-3 AC-3 AC-1 AC-1
Efficiency
3)
0.96
Weight IP 20 [kg] 8 8 8,5 8,5 10,5 10,5 10,5
Weight IP 54 [kg] 11.5 11.5 12 12 14 14 14
Power loss at max. load. [W] Total 67 92 110 139 198 250 295
Enclosure VLT type Bookstyle IP 20/Compact IP 20/IP 54
(Bookstyle IP 20 is available in the VLT 6002-6011 power range)
■■
■■
■ Technical data, mains supply 3 x 380 - 460 V
According to international requirements
VLVL
VLVL
VL
T typeT type
T typeT type
T type
60166016
60166016
6016
60226022
60226022
6022
60276027
60276027
6027
60326032
60326032
6032
60426042
60426042
6042
60526052
60526052
6052
60626062
60626062
6062
Output current I
VLT,N
[A] (380-415 V) 24.0 32.0 37.5 44.0 61.0 73.0 90.0
I
VLT, MAX
(60 s) [A] (380-415 V) 26.4 35.2 41.3 48.4 67.1 80.3 99.0
I
VLT,N
[A] (440-460 V) 21.0 27.0 34.0 40.0 52.0 65.0 77.0
I
VLT, MAX
(60 s) [A] (440-460 V) 23.1 29.7 37.4 44.0 57.2 71.5 84.7
Output S
VLT,N
[kVA] (400 V) 17.3 23.0 27.0 31.6 43.8 52.5 64.7
S
VLT,N
[kVA] (460 V) 16.7 21.5 27.1 31.9 41.4 51.8 61.3
Typical shaft output P
VLT,N
[kW] 11 15 18.5 22 30 37 45
Typical shaft output P
VLT,N
[HP] 15 20 25 30 40 50 60
Max. cable cross-section
to motor and DC-bus [mm
2
/AWG] 16/6 16/6 16/6 16/6 35/2 35/2 50/0
Min. cable cross-section
to motor and DC-bus
4)
[mm
2
/AWG] 10/8 10/8 10/8 10/8 10/8 10/8 16/6
Max. input current I
L,N
[A] (380 V) 32.0 32.0 37.5 44.0 60.0 72.0 89.0
I
L,N
[A] (460 V) 27.6 27.6 34.0 41.0 53.0 64.0 77.0
Max. cable cross-section,
power [mm
2
]/[AWG] 16/6 16/6 16/6 16/6 35/2 35/2 50/0
Max. pre-fuses [A]/UL
1 )
[A] 63/40 63/40 63/50 63/60 80/80 100/100 125/125
Efficiency at rated frequency 0.96
Weight IP 20 [kg] 23 23 23 30 30 48 48
Weight IP 54 [kg] 48 48 48 51 61 67 70
Power loss at max. load. [W] 419 559 655 768 1065 1275 1571
Enclosure IP 20/IP 54
■■
■■
■ Mains supply 3 x 380 - 460 V
According to international requirements
1. If UL/cUL is to be complied with, pre-fuses type Bussmann KTS-R or similar must be used. In the remainder of the world, the first-
mentioned pre-fuses must be used. These pre-fuses must be semi-conductor fuses of the gL type. The fuses must be placed to
protect a circuit capable of supplying max. 100,000 amps rms (symmetrical), 500 V maximum.
2. American Wire Gauge.
3. Measured using 30 m screened/armoured motor cable at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-section.
