VLT
®
6000 HVAC
47MG.60.B1.02 - VLT is a registered Danfoss trade mark
Installation
VLVL
VLVL
VL
T typeT type
T typeT type
T type
60756075
60756075
6075
61006100
61006100
6100
61256125
61256125
6125
61506150
61506150
6150
61756175
61756175
6175
62256225
62256225
6225
62756275
62756275
6275
Output current I
VLT,N
[A] (380-415 V) 106 147 177 212 260 315 368
I
VLT, MAX
(60 s) [A] (380-415 V) 117 162 195 233 286 347 405
I
VLT,N
[A] (440-460 V) 106 130 160 190 240 302 361
I
VLT, MAX
(60 s) [A] (440-460 V) 117 143 176 209 264 332 397
Output S
VLT,N
[kVA] (400 V) 73 102 123 147 180 218 255
S
VLT,N
[kVA] (460 V) 84,5 104 127 151 191 241 288
Typical shaft output (380-415 V) P
VLT,N
[kW] 55 75 90 110 132 160 200
Typical shaft output (440-460 V) P
VLT, N
[HP] 75 100 125 150 200 250 300
Max. cross-section of copper cable
to motor and DC-bus (380-415 V) [mm
2
] 70 95 120 2x70 2x70 2x95 2x120
Max. cross-section of copper cable
to motor and DC-bus (440-460 V) [mm
2
] 70 70 95 2x70 2x70 2x95 2x120
Max. cross-section of aluminium cable
to motor and DC-bus (380-415 V) [mm
2
] 95 90 120 2x70 2x95 2x120 2x150
Max. cross-section of aluminium cable
to motor and DC-bus (440-460 V) [mm
2
] 70 120 150 2x70 2x120 2x120 2x150
Max. cross-section of copper cable
to motor and DC-bus (380-415 V) [AWG] 1/0 3/0 4/0 2x1/0 2x2/0 2x3/0 2x250mcm
Max. cross-section of copper cable
to motor and DC-bus (440-460 V) [AWG] 1/0 2/0 3/0 2x1/0 2x1/0 2x3/0 2x4/0
Max. cross-section of aluminium cable
to motor and DC-bus (380-415 V) [AWG] 3/0 250mcm 300mcm 2x2/0 2x4/0 2x250mcm 2x350mcm
Max. cross-section of aluminium cable
to motor and DC-bus (440-460 V) [AWG] 3/0 4/0 250mcm 2x2/0 2x3/0 2x250mcm 2x300mcm
Max. cross-section of cable to motor,
and DC-bus
4)
[mm
2/
AWG] 10/8 10/8 10/8 10/8 10/8 16/6 16/6
■■
■■
■ Technical data, mains supply 3 x 380 - 460 V
According to international requirements
Max. input current I
L,N
[A] (400 V) 131 155 217 262 310 384 476
I
L,N
[A] (460 V) 117 155 192 236 277 355 457
Max. cross-section of copper cable
to power (380-415 V) [mm
2
] 70 95 120 2x70 2x70 2x95 2x120
Max. cross-section of copper cable
to power (440-460 V) [mm
2
] 70 70 95 2x70 2x70 2x95 2x120
Max. cross-section of aluminium cable
to power (380-415 V) [mm
2
] 95 90 120 2x70 2x95 2x120 2x150
Max. cross-section of aluminium cable
to power (440-460 V) [mm
2
] 70 120 150 2x70 2x120 2x120 2x150
Max. cross-section of copper cable
to power (380-415 V) [AWG] 1/0 3/0 4/0 2x1/0 2x2/0 2x3/0 2x250mcm
Max. cross-section of copper cable
to power (440-460 V) [AWG] 1/0 2/0 3/0 2x1/0 2x1/0 2x3/0 2x4/0
Max. cross-section of aluminium cable
to power (380-415V) [AWG] 3/0 250mcm 300mcm 2x2/0 2x4/0 2x250mcm 2x350mcm
Max. cross-section of aluminium cable
to power (440-460 V) [AWG] 3/0 4/0 250mcm 2x2/0 2x3/0 2x250mcm 2x300mcm
Min. cable cross-section to motor,
and DC-bus
4)
[mm
2/
AWG] 10/8 10/8 10/8 10/8 10/8 16/6
Max. pre-fuses [A]/UL
1 )
[A] 150/150 250/220 250/250 300/300 350/350 450/400 500/500
Integral pre-fuses [A]/UL
1 )
[A] 15/15 15/15 15/15 30/30 30/30 30/30 30/30
Pre-fuses SMPS [A]/UL
1 )
[A] 5.0/5.0
Weight IP 00 [kg] 109 109 109 146 146 146 146
Weight IP 20 [kg] 121 121 121 161 161 161 161
Weight IP 54 [kg] 124 124 124 177 177 177 177
Efficiency at rated frequency 0.96-0.97
Power loss at max. load [W] 1430 1970 2380 2860 3810 4770 5720
Enclosure IP 00 / IP 20/ IP 54
1. If UL/cUL is to be complied with, pre-fuses type Bussmann KTN-R, KTS-R or similar must be used.
In the remainder of the world, the first-mentioned pre-fuses must be used. These pre-fuses must be semi-conductor fuses of the gL
type. The fuses must be placed to protect a circuit capable of supplying max. 100,000 amps rms (symmetrical),
500 V maximum.
2. American Wire Gauge.
3. Measured using 30 m screened/armoured motor cable at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-section.
