Digital inputs:
The digital inputs can be used for controlling various
functions of the VLT frequency converter.
Digital outputs:
There are four digital outputs, two of which activate a
relay switch. The outputs are able to supply a 24 V DC
(max. 40 mA) signal.
f
JOG
The output frequency from the VLT frequency
converter transmitted to the motor when the jog
function is activated (via digital terminals or serial
communication).
f
M
The output frequency from the VLT frequency
converter transmitted to the motor.
f
M,N
The rated motor frequency (nameplate data).
f
MAX
Maximum output frequency transmitted to the motor.
f
MIN
Minimum output frequency transmitted to the motor.
I
M
The current transmitted to the motor.
I
M,N
The rated motor current (nameplate data).
Initializing:
If initializing is carried out (see parameter 620
Operating mode), the VLT frequency converter
returns to the factory setting.
I
VLT,MAX
The maximum output current.
I
VLT,N
The rated output current supplied by the VLT
frequency converter.
LCP:
The control panel, which makes up a complete inter-
face for control and programming of VLT 6000 HVAC.
The control panel is detachable and may, as an alter-
native, be installed up to 3 metres away from the VLT
frequency converter, i.e. in a front panel, by means of
the installation kit option.
■■
■■
■ Definitions
Definitions are given in alphabetical order.
Analogue inputs:
The analogue inputs can be used for controlling
various functions of the VLT frequency converter.
There are two types of analogue inputs:
Current input, 0-20 mA
Voltage input, 0-10 V DC.
Analogue ref.
A signal transmitted to input 53, 54 or 60. Can be
voltage or current.
Analogue outputs:
There are two analogue outputs, which are able to
supply a signal of 0-20 mA, 4-20 mA or a digital
signal.
Automatic motor adjustment, AMA:
Automatic motor adjustment algorithm, which
determines the electrical parameters for the
connected motor, at standstill.
AWG:
Means American Wire Gauge, i.e. the American
measuring unit for cable cross-section.
Control command:
By means of the control unit and the digital inputs, it
is possible to start and stop the connected motor.
Functions are divided into two groups, with the
following priorities:
Group 1 Reset, Coasting stop, Reset and Coasting
stop, DC braking, Stop and the [OFF/
STOP] key.
Group 2 Start, Pulse start, Reversing, Start
reversing, Jog and Freeze output
Group 1 functions are called Start-disable
commands. The difference between group 1 and
group 2 is that in group 1 all stop signals must be
cancelled for the motor to start. The motor can then
be started by means of a single start signal in group
2.
A stop command given as a group 1 command
results in the display indication STOP.
A missing stop command given as a group 2
command results in the display indication STAND BY.
