Programming
Analogue input 54 [V] Analogue input 54 [V]
Analogue input 54 [V] Analogue input 54 [V]
Analogue input 54 [V] states the voltage value on
terminal 54.
Analogue input 60 [mA]Analogue input 60 [mA]
Analogue input 60 [mA]Analogue input 60 [mA]
Analogue input 60 [mA] states the voltage value on
terminal 60.
Pulse reference [Hz]Pulse reference [Hz]
Pulse reference [Hz]Pulse reference [Hz]
Pulse reference [Hz] states a pulse frequency in Hz
connected to terminal 17 or terminal 29.
External reference [%]External reference [%]
External reference [%]External reference [%]
External reference [%] gives the sum of the external
references as a percentage (the sum of analogue/
pulse/serial communication) in the range from
Minimum reference, Ref
MIN
to Maximum reference,
Ref
MAX
.
Heat sink temp. [°C]Heat sink temp. [°C]
Heat sink temp. [°C]Heat sink temp. [°C]
Heat sink temp. [°C] states the present heat sink
temperature of the VLT frequency converter. The cut-
out limit is 90 ± 5°C; cutting back in occurs at 60 ±
5°C.
LCD display textLCD display text
LCD display textLCD display text
LCD display text shows the text programmed in
parameter 533 Display text 1 and 534 Display text 2
via the serial communication port.
008 Small display readout 1.1
(SMALL READOUT 1)
Value:
See parameter 007 Large display readout
✭ Reference [Unit] [2]
Function:
This parameter enables a choice of the first of three
data values to be shown on the display, line 1,
position 1.
This is a useful function, i.a. when setting the PID
regulator, in order to see how the process reacts to a
change of reference.
For display read-outs, press the [DISPLAY/STATUS]
button. Data option LCP display text [27] cannot be
selected with small display readout.
Description of choice:
There is a choice of 26 different data values, see
parameter 007 Large display readout.
009 Small display readout 1.2
(SMALL READOUT 2)
Value:
See parameter 007 Large display readout
★ Motorcurrent [A] [5]
Function:
See the functional description for parameter 008
Small display readout.
Description of choice:
There is a choice of 26 different data values, see
parameter 007 Large display readout.
010 Small display readout 1.3
(SMALL READOUT 3)
Value:
Se parameter 007 Large display readout
★ Power [kW] [6]
Function:
See the functional description for parameter 008
Small data readout.
Description of choice:
There is a choice of 26 different data values, see
parameter 007 Large display readout.
011 Unit of local reference
(UNIT OF LOC REF)
Value:
★ Hz (HZ) [0]
% of output frequency range (%) (% OF FMAX) [1]
Function:
This parameter decides the local reference unit.
Description of choice:
Choose the required unit for local reference.
012 Hand start on LCP
(HAND START BTTN)
Value:
Disable (DISABLE) [0]
★ Enable (ENABLE) [1]
Function:
This parameter allows selection/deselection of the
Hand start key on the control panel.
Description of choice:
If Disable [0] is selected in this parameter, the [HAND
START] key will be inactive.
