7.3.5 Differential Mode (DM) RFI Filter Card
1. Disconnect the cables from MK105, MK106, and
MK107
2. Remove the differential mode RFI filter card by
removing the four screws (T-25) from the
standoffs.
Reinstall in the reverse order of this procedure. See
Table 1.7 for torque tightening values.
7.3.6 Capacitor Bank Assembly
Note that the RFI filter can remain attached to the cover
plate when removing the capacitor bank assembly.
Disconnect the wiring from the RFI filter when leaving the
filter attached.
1. Note the color of the wires attached to the DC
bus terminals on the right side of the capacitor
bank assembly for proper reassembly.
2. Remove the two nuts (0.39 in [10 mm]) from the
DC bus terminals (not shown).
3. Remove the capacitor bank assembly by
removing the four retaining nuts (0.39 in [10
mm]) at the bottom of the capacitor bank
assembly and four retaining nuts (T-30) from the
top.
NOTE!
Reinstall in the reverse order of this procedure. See
Table 1.7 for torque tightening values.
D-Frame Sizes Disassembly a... VLT Advanced Active Filter AAF006 D and E Frames Service Manual
7-12 MG90Z122 - VLT
®
is a registered Danfoss trademark
77
