7. Remove the current sensor by removing the nut
(0.32 in [8 mm]), one on each side of the current
sensor.
Reinstall in the reverse order of this procedure. See
Table 1.7 for torque tightening values.
8.3.8 Fan Transformer
1. Disconnect the line power input cabling from
terminals L1, L2, L3, and the ground connector.
2. Disconnect the inline connector from the fan
transformer (not shown).
3. Remove the fan transformer by removing the nut
(0.51 in [13 mm]) in the center of the fan
transformer.
Reinstall in the reverse order of this procedure. See
Table 1.7 for torque tightening values.
8.3.9
Fan
1. Disconnect the line power input cabling from
terminals L1, L2, L3, and the ground connector.
2. Disconnect the Molex connector from the fan
assembly.
3. Remove the fan assembly by removing six nuts
(0.39 in [10 mm]).
Reinstall in the reverse order of this procedure. See
Table 1.7 for torque tightening values.
8.3.10
Damping Resistors
1. Remove the input terminal mounting plate in
accordance with the procedure.
2. Remove the damping resistor bus bars by
removing the screws (T-20).
3. Remove the damping resistor by removing the
screws (T-20) on either side of the damping
resistor.
Reinstall in the reverse order of this procedure. See
Table 1.7 for torque tightening values.
E-Frame Sizes Disassembly a... VLT Advanced Active Filter AAF006 D and E Frames Service Manual
8-18 MG90Z122 - VLT
®
is a registered Danfoss trademark
88
