8.2 Passive Section (Top) Instructions
1
2
3
4
5
6
7
8
9
10
130BX405
Figure 8.1 Control Card and Mounting Plate, Support Bracket, Power Card and Mounting Plate
1
Control card terminal block 6 FU4
2 Control card 7 Power card mounting plate
3 Active filter (AAF) card 8 Power card
4 Control card mounting plate 9 Mounting nut
5 FU5 10 Control card assembly support bracket
Table 8.1
E-Frame Sizes Disassembly a... VLT Advanced Active Filter AAF006 D and E Frames Service Manual
8-2 MG90Z122 - VLT
®
is a registered Danfoss trademark
88
