4.2.6 Weight Information
Crate
Length
(mm)
Crate
Weight
(kg)
(lbs) Cabinet
Weight
(kg)
(lbs) Content
(kg)
(lbs) Total
Package
(kg)
(lbs) Package Contents
600 120 252 57 126 159 351 336 729 Cabinet and D Frame frequency converter
800 130 273 76 168 306 675 512 1116 Inverter Modules Qty. 2
1200 160 336 115 253 459 1012 734 1601 Inverter Modules Qty. 3
1200 160 336 115 253 318 701 593 1290 600mm Cabinet Qty. 2, D Frame frequency
conveters Qty. 2
1600 260 546 153 337 612 1349 1025 2232 2 x 800mm Cabinet with Inverter Modules
Qty. 2
2000 320 672 191 421 765 1687 1276 2780 1200mm Cabinet with Inverter Modules
Qty. 3, 800mm Cabinet with Inverter
Modules Qty. 2
2400 380 798 229 505 918 2024 1527 3327 2 x 1200mm Cabinet with Inverter Modules
Qty. 3
2800 440 924 267 590 1071 2361 1778 3875 1200mm Cabinet with Inverter Modules
Qty. 3, 2 x 800mm Cabinet with Inverter
Modules Qty. 2
Table 4.1 Weight Based on Shipping Package Crate Size
4.3 Mechanical Installation
The mechanical installation of the frequency converters must
be prepared carefully to avoid additional work during the
installation. Review the mechanical drawings to become
familiar with the space demands.
4.3.1 Tools Needed
To perform the mechanical installation the following tools
are needed:
•
Tape measure
•
Wrench with relevant metric sockets (7-17mm)
•
Extensions to wrench
•
Lifting bar to lift the unit (rod or tube Ø 20mm)
able to lift minimum 400kg.
•
Crane or other lifting aid to place the frequency
converter in position
4.3.2 General Considerations
Space
Ensure proper space above and below the frequency
converter to allow airflow and cable access.
Wire access
Ensure that proper cable access is present including
necessary bending allowance. As the IP00 enclosure is open
at the bottom, the cables must be secured to the back panel
of the enclosure where the frequency converter is mounted,
i.e. by using cable clamps.
