Danfoss VLT AFE 302 - Parameters: 8-** Communications and Options

5.6 Parameters: 8-** Communications and
Options
5.6.1 8-0* General Settings
8-01 Control Site
Option: Function:
[0] * Digital and ctrl. word Control by using both digital input
and control word.
[1] Digital only Control by using digital inputs only.
[2] Control word only Control by using control word only.
The setting in this parameter overrides the settings in par.
8-50 to 8-56.
8-02 Control Word Source
Option: Function:
[0] None
[1] * FC RS485
[2] FC USB
8-03 Control Word Timeout Time
Range: Function:
1.0 s* [0.1 -
18000.0 s]
Enter the maximum time expected to pass
between the reception of two consecutive
telegrams. If this time is exceeded, it
indicates that the serial communication has
stopped. The function selected in
8-04 Control Word Timeout Function will then
be carried out. The time-out counter is
triggered by a valid control word.
This parameter specifies which action should be performed,
if a timeout of the control word occurs.
8-04 Control Word Timeout Function
Option: Function:
[0] * Off
[2] Stop
[5] Stop and trip
8-06 Reset Control Word Timeout
Option: Function:
[0] * Do not reset
[1] Do reset
5.6.2 8-1* Control Word Settings
Parameters for configuring the option control word profile.
This parameter selects the interpretation of the control word
and status word. Valid selections are determined by installed
option.
8-10 Control Word Settings
Option: Function:
[0] * FC AFE profile
Bus Control Word
Bit AFE Profile
Bit = 0 Bit = 1
0 - -
1 - -
2 - -
3 - -
4 - -
5 - -
6 Stop Start
7 No Function Reset
8 - -
9 - -
10 Data not valid Data valid
11 - -
12 - -
13 - -
14 - -
15 - -
