5-14 Terminal 32 Digital Input
Option: Function:
[0] * No operation
[1] Reset
[8] Start
[23] * Set-up select bit 0 Select Set-up select bit 0 or Select Set-
up select bit 1 to select one of the four
set-ups. Set0-10 Active Set-up to Multi
Set-up.
[24] * Set-up select bit 1 (Default Digital input 32): Same as Set-
up select bit 0 [23].
5-15 Terminal 33 Digital Input
Option: Function:
[0] * No operation
[1] Reset
[8] Start
[23] * Set-up select bit 0 Select Set-up select bit 0 or Select Set-
up select bit 1 to select one of the four
set-ups. Set0-10 Active Set-up to Multi
Set-up.
[24] * Set-up select bit 1 (Default Digital input 32): Same as Set-
up select bit 0 [23].
5.4.2 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
terminal 27 in par. 5-01 Terminal 27 Mode, and set the I/O
function for terminal 29 in par. 5-02 Terminal 29 Mode. These
parameters cannot be adjusted while the AFE is running.
5-30 Terminal 27 Digital Output
Option: Function:
[0] No operation
Default for all digital outputs and relay
outputs
[1] Control ready The control board receives supply
voltage.
[2] Drive ready The frequency converter is ready for
operation and applies a supply signal
on the control board.
[9] Alarm An alarm activates the output. There
are no warnings.
[254] Soft charge ready DC bus charged
[255] * DC-link on ref. AFE running and motor operation
allowed.
5-31 Terminal 29 Digital Output
Option: Function:
[0] * No operation
Default for all digital outputs and relay
outputs
[1] Control ready The control board receives supply
voltage.
[2] Drive ready The frequency converter is ready for
operation and applies a supply signal on
the control board.
[9] Alarm An alarm activates the output. There are
no warnings.
[254] Soft charge ready DC bus charged
[255] DC-link on ref. AFE running and motor operation
allowed.
In this parameter, the function for the terminal 29 digital
output is selected.
5.4.3
5-4* Relays
Parameters for configuring the timing and the output
functions for the relays
(Relay 1 [0], Relay 2 [1])
5-40 Function Relay
Option: Function:
[0] No operation
Default for all digital outputs and relay
outputs
[1] Control ready The control board receives supply
voltage.
[2] Drive ready The frequency converter is ready for
operation and applies a supply signal
on the control board.
[9] Alarm An alarm activates the output. There
are no warnings.
[254] * Soft charge ready DC bus charged
[255] DC-link on ref. AFE running and motor operation
allowed.
In this parameter, the function for the relay outputs is
selected. The selection of each mechanical relay is realised in
an array parameter.
5-41 On Delay, Relay
Range: Function:
0.01 s* [0.01 - 600.00
s]
This parameter makes it possible to delay
the cut-in time of the relays. The selection
of each mechanical relay is realised in an
array parameter.
5-42 Off Delay, Relay
Range: Function:
0.01 s* [0.01 - 600.00
s]
This parameter makes it possible to delay
the cut-out time of the relays. The
selection of each mechanical relay is
realised in an array parameter.
How to Programme
