Danfoss VLT AHF 005 Operating Instructions

Mains Supply 3x380-480 V AC
P315 P355 P400 P450
Typical Shaft output at 400 V
[kW]
315 355 400 450
Typical Shaft output at 460 V
[HP]
450 500 600 600
Enclosure IP21 E1 E1 E1 E1
EnclosureIP54 E1 E1 E1 E1
Enclosure IP00 E2 E2 E2 E2
Output current
Continuous
(at 400 V) [A]
600 658 745 800
Intermittent (60 sec overload)
(at 400 V) [A]
660 724 820 880
Continuous
(at 460/ 480 V) [A]
540 590 678 730
Intermittent (60 sec overload)
(at 460/ 480 V) [A]
594 649 746 803
Continuous KVA
(at 400 V) [KVA]
416 456 516 554
Continuous KVA
(at 460 V) [KVA]
430 470 540 582
Max. input current
Continuous
(at 400 V ) [A]
590 647 733 787
Continuous
(at 460/ 480 V) [A]
531 580 667 718
Max. cable size, mains, motor
and load share [mm
2
(AWG
2)
)]
4x240
(4x500 mcm)
4x240
(4x500 mcm)
4x240
(4x500 mcm)
4x240
(4x500 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
Max. external pre-fuses [A]
1
700 900 900 900
Estimated power loss
at rated max. load [W]
4)
, 400
V
6790 7701 8879 9670
Estimated power loss
at rated max. load [W]
4)
, 460
V
6082 6953 8089 8803
Weight,
enclosure IP21, IP 54 [kg]
263 270 272 313
Weight,
enclosure IP00 [kg]
221 234 236 277
Efficiency
4)
0.98
Output frequency 0 - 600 Hz
Heat sink overtemp. trip
110°C
Power card ambient trip
68 °C
Table 7.2
General Specifications
VLT HVAC Drive FC 102 Operating Instructions
MG11F402 - Rev. 2013-12-16 121
7 7
