Mains Supply 3x380-480 V AC
P500 P560 P630 P710 P800 P1M0
Typical Shaft output at 400 V [kW] 500 560 630 710 800 1000
Typical Shaft output at 460 V [HP] 650 750 900 1000 1200 1350
Enclosure IP21, 54 without/ with
options cabinet
F1/F3 F1/F3 F1/F3 F1/F3 F2/F4 F2/F4
Output current
Continuous
(at 400 V) [A]
880 990 1120 1260 1460 1720
Intermittent (60 sec overload)
(at 400 V) [A]
968 1089 1232 1386 1606 1892
Continuous
(at 460/ 480 V) [A]
780 890 1050 1160 1380 1530
Intermittent (60 sec overload)
(at 460/ 480 V) [A]
858 979 1155 1276 1518 1683
Continuous KVA
(at 400 V) [KVA]
610 686 776 873 1012 1192
Continuous KVA
(at 460 V) [KVA]
621 709 837 924 1100 1219
Max. input current
Continuous
(at 400 V ) [A]
857 964 1090 1227 1422 1675
Continuous (at 460/ 480 V) [A] 759 867 1022 1129 1344 1490
Max. cable size,motor [mm
2
(AWG
2)
)]
8x150
(8x300 mcm)
12x150
(12x300 mcm)
Max. cable size,mains F1/F2 [mm
2
(AWG
2)
)]
8x240
(8x500 mcm)
Max. cable size,mains F3/F4 [mm
2
(AWG
2)
)]
8x456
(8x900 mcm)
Max. cable size, loadsharing [mm
2
(AWG
2)
)]
4x120
(4x250 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
4x185
(4x350 mcm)
6x185
(6x350 mcm)
Max. external pre-fuses [A]
1
1600 2000 2500
Est. power loss at rated max. load
[W]
4)
, 400 V, F1 & F2
10647 12338 13201 15436 18084 20358
Est. power loss at rated max. load
[W]
4)
, 460 V, F1 & F2
9414 11006 12353 14041 17137 17752
Max added losses of A1 RFI, Circuit
Breaker or Disconnect, & Contactor,
F3 & F4
963 1054 1093 1230 2280 2541
Max Panel Options Losses 400
Weight,
enclosure IP21, IP 54 [kg]
1004/ 1299 1004/ 1299 1004/ 1299 1004/ 1299 1246/ 1541 1246/ 1541
Weight Rectifier
Module [kg]
102 102 102 102 136 136
Weight Inverter
Module [kg]
102 102 102 136 102 102
Efficiency
4)
0.98
Output frequency 0-600 Hz
Heat sink overtemp. trip
95 °C
Power card ambient trip
68 °C
Table 7.3
General Specifications
VLT HVAC Drive FC 102 Operating Instructions
122 MG11F402 - Rev. 2013-12-16
