Group Title Function
13** Smart Logic Controller Parameters used to configure the built-in Smart Logic Controller (SLC). The SLC can be used for
•
simple functions such as
-
comparators (e.g. if running above x Hz, activate output relay)
-
timers (e.g. when a start signal is applied, first activate output relay to open supply
air damper and wait x seconds before ramping up)
•
complex sequence of user-defined actions executed by the SLC when the associated user-
defined event is evaluated as TRUE by the SLC. (For example, initiate an economiser mode in
a simple AHU cooling application control scheme where there is no BMS. For such an
application the SLC can monitor the outside air relative humidity and if it is below a defined
value, the supply air temperature setpoint could be automatically increased. With the
frequency converter monitoring the outside air relative humidity and supply air temperature
via its analog inputs, and controlling the chilled water valve via one of the extended PI(D)
loops and an analog output, it would then modulate that valve to maintain a higher supply
air temperature).
The SLC can often replace the need for other external control equipment.
14** Special Functions Parameters used to configure special functions of the frequency converter including:
•
Setting of the switching frequency to reduce audible noise from the motor (sometimes
required for fan applications)
•
Kinetic back-up function (especially useful for critical applications in semi-conductor instal-
lations where performance under mains dip/mains loss is important)
•
Mains imbalance protection
•
Automatic reset (to avoid the need for a manual reset of Alarms)
•
Energy optimisation parameters (which typically do not need changing but enable fine
tuning of this automatic function (if necessary) ensuring the frequency converter and motor
combination operate at their optimum efficiency at full and partial load conditions)
•
Auto-derating functions (which enable the frequency converter to continue operation at
reduced performance under extreme operating conditions ensuring maximum up time)
15** FC Information Parameters providing operating data and other frequency converter information including:
•
Operating and running hour counters
•
kWh counter; resetting of the running and kWh counters
•
Alarm/fault log (where the past 10 alarms are logged along with any associated value and
time)
•
Frequency converter and option card indentification parameters such as code number and
software version
16** Data Readouts Read only parameters which display the status/value of many operating variables which can be
displayed on the LCP or viewed in this parameter group. These parameters can be particularly
useful during commissioning when interfacing with a BMS via a high level interface.
18** Info & Readouts Read only parameters which display the last 10 prevantative maintenance log items, actions and
time and the value of analog inputs and outputs on the Analog I/O option card which can be
particularly useful during commissioning when interfacing with a BMS via a high level interface.
How to Programme VLT HVAC Drive FC 102 Operating Instructions
