In addition to the text and alarm code on the adjustable
frequency drive LCP, there are three status indicator lights.
Auto
on
Reset
Hand
on
Off
Back
Cancel
Info
OK
On
Alarm
Warn.
130BB467.10
Figure 8.3 Status Indicator Lights
Warning LED Alarm LED
Warning On Off
Alarm Off On (Flashing)
Trip Lock On On (Flashing)
Table 8.1 Status Indicator Lights Explanations
Warnings and Alarms
VLT
®
AQUA Drive
Instruction Manual
