10.1.3 Line Power Supply 1 x 380–480 V AC
Line Power Supply 1 x 380 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P7K5
7.5
P11K
11
P18K
18.5
P37K
37
Typical Shaft Output [HP] at 460 V 10 15 25 50
IP21/NEMA 1 B1 B2 C1 C2
IP55/NEMA 12 B1 B2 C1 C2
IP66 B1 B2 C1 C2
Output current
Continuous (3 x 380–440 V) [A] 16 24 37.5 73
Intermittent (3 x 380-440 V) [A] 17.6 26.4 41.2 80.3
Continuous (3 x 441–480 V) [A] 14.5 21 34 65
Intermittent (3 x 441–480 V) [A] 15.4 23.1 37.4 71.5
Continuous kVA (400 V AC) [kVA] 11.0 16.6 26 50.6
Continuous kVA (460 V AC) [kVA] 11.6 16.7 27.1 51.8
Max. input current
Continuous (1 x 380–440 V) [A] 33 48 78 151
Intermittent (1 x 380–440 V) [A] 36 53 85.8 166
Continuous (1 x 441–480 V [A] 30 41 72 135
Intermittent (1 x 441–480 V [A] 33 46 79.2 148
Max. pre-fuses
1)
[A]
63 80 160 250
Additional specifications
Estimated power loss at rated max. load [W]
4)
300 440 740 1480
Max. cable size (line power, motor, brake) [mm
2
]/(AWG)
2)
[10]/(7) [35]/(2) [50]/(1/0) [120]/(4/0)
Weight enclosure IP21 (lb [kg]) 50.71 [23] 59.53 [27] 99.21 [45] 143.3 [65]
Weight enclosure IP55 (lb [kg]) 50.71 [23] 59.53 [27] 99.21 [45] 143.3 [65]
Weight enclosure IP66 (lb [kg]) 50.71 [23] 59.53 [27] 99.21 [45] 143.3 [65]
Efficiency
3)
0.96 0.96 0.96 0.96
Table 10.4 Line Power Supply 1 x 380 V AC - Normal Overload 110% for 1 Minute
Specifications
VLT
®
AQUA Drive
Instruction Manual
10-4 MG20M922 - VLT
®
is a registered Danfoss trademark
10
10
