Danfoss VLT AQUA Drive FC 202

Line Power Supply 3 x 200–240 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P5K5
5.5
P7K5
7.5
P11K
11
P15K
15
P18K
18.5
P22K
22
P30K
30
P37K
37
P45K
45
Typical Shaft Output [HP] at 208 V 7.5 10 15 20 25 30 40 50 60
IP20/NEMA Chassis
*
B3 B3 B3 B4 B4 C3 C3 C4 C4
IP21/NEMA 1 B1 B1 B1 B2 C1 C1 C1 C2 C2
IP55/NEMA 12 B1 B1 B1 B2 C1 C1 C1 C2 C2
IP66 B1 B1 B1 B2 C1 C1 C1 C2 C2
Output current
Continuous (3 x 200–240 V) [A] 24.2 30.8 46.2 59.4 74.8 88.0 115 143 170
Intermittent (3 x 200–240 V) [A] 26.6 33.9 50.8 65.3 82.3 96.8 127 157 187
Continuous kVA (208 V AC) [kVA] 8.7 11.1 16.6 21.4 26.9 31.7 41.4 51.5 61.2
Max. input current
Continuous (3 x 200–240 V) [A] 22.0 28.0 42.0 54.0 68.0 80.0 104.0 130.0 154.0
Intermittent (3 x 200–240 V) [A] 24.2 30.8 46.2 59.4 74.8 88.0 114.0 143.0 169.0
Max. pre-fuses
1)
[A]
63 63 63 80 125 125 160 200 250
Additional specifications
Estimated power loss at rated
max. load [W]
4)
269 310 447 602 737 845 1140 1353 1636
Max. cable size (line power, motor,
brake)
[mm
2
]/(AWG)
2)
[10]/(7) [35]/(2) [50]/(1/0) [95]/(4/0)
[120]/
(250
MCM)
Weight enclosure IP20 (lb [kg])
26.46 [12] 26.46 [12] 26.46 [12]
51.81
[23.5]
51.81
[23.5]
77.16 [35] 77.16 [35] 110.23 [50]
110.23
[50]
Weight enclosure IP21 (lb [kg]) 50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65] 143.3 [65]
Weight enclosure IP55 (lb [kg]) 50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65] 143.3 [65]
Weight enclosure IP66 (lb [kg]) 50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65] 143.3 [65]
Efficiency
3)
0.96 0.96 0.96 0.96 0.96 0.97 0.97 0.97 0.97
Table 10.3 Line Power Supply 3 x 200–240 V AC - Normal Overload 110% for 1 Minute
*
B3+4 and C3+4 may be converted to IP21 using a conversion kit
(contact Danfoss)
