10.1.2 Line Power Supply 3 x 200–240 V AC
Line Power Supply 3 x 200–240 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
PK25
0.25
PK37
0.37
PK55
0.55
PK75
0.75
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P3K7
3.7
Typical Shaft Output [HP] at 208 V 0.25 0.37 0.55 0.75 1.5 2.0 2.9 4.0 4.9
IP20/NEMA Chassis A2 A2 A2 A2 A2 A2 A2 A3 A3
IP21/NEMA 1 A2 A2 A2 A2 A2 A2 A2 A3 A3
IP55/NEMA 12 A5 A5 A5 A5 A5 A5 A5 A5 A5
IP66 A5 A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous (3 x 200–240 V) [A] 1.8 2.4 3.5 4.6 6.6 7.5 10.6 12.5 16.7
Intermittent (3 x 200–240 V) [A] 1.98 2.64 3.85 5.06 7.26 8.3 11.7 13.8 18.4
Continuous kVA (208 V AC) [kVA] 0.65 0.86 1.26 1.66 2.38 2.70 3.82 4.50 6.00
Max. input current
Continuous (3 x 200–240 V) [A] 1.6 2.2 3.2 4.1 5.9 6.8 9.5 11.3 15.0
Intermittent (3 x 200–240 V) [A] 1.7 2.42 3.52 4.51 6.5 7.5 10.5 12.4 16.5
Max. pre-fuses
1)
[A]
10 10 10 10 20 20 20 32 32
Additional specifications
Estimated power loss at rated max. load [W]
4)
21 29 42 54 63 82 116 155 185
Max. cable size (line power, motor, brake) [mm
2
]/(AWG)
2)
[0.2–4]/(4–10)
Weight enclosure IP20 (lb [kg]) 10.8
[4.9]
10.8
[4.9]
10.8
[4.9]
10.8
[4.9]
10.8
[4.9]
10.8
[4.9]
10.8
[4.9]
14.55
[6.6]
14.55
[6.6]
Weight enclosure IP21 (lb [kg]) 12.13
[5.5]
12.13
[5.5]
12.13
[5.5]
12.13
[5.5]
12.13
[5.5]
12.13
[5.5]
12.13
[5.5]
16.54
[7.5]
16.54
[7.5]
Weight enclosure IP55 (lb [kg]) 29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
Weight enclosure IP66 (lb [kg]) 29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
Efficiency
3)
0.94 0.94 0.95 0.95 0.96 0.96 0.96 0.96 0.96
Table 10.2 Line Power Supply 3 x 200–240 V AC - Normal Overload 110% for 1 Minute
Specifications
VLT
®
AQUA Drive
Instruction Manual
10-2 MG20M922 - VLT
®
