10.1.6 Line Power Supply 3 x 525–690 V AC
Line Power Supply 3 x 525–690 V AC
Adjustable Frequency Drive
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P4K0
4
P5K5
5.5
P7K5
7.5
Enclosure IP20 (only) A3 A3 A3 A3 A3 A3 A3
Output current High overload 110% for 1 min
Continuous (3x525–550 V) [A] 2.1 2.7 3.9 4.9 6.1 9 11
Intermittent (3x525–550 V) [A] 2.3 3.0 4.3 5.4 6.7 9.9 12.1
Continuous kVA (3x551–690 V) [A] 1.6 2.2 3.2 4.5 5.5 7.5 10
Intermittent kVA (3x551–690 V) [A] 1.8 2.4 3.5 4.9 6.0 8.2 11
Continuous kVA 525 V AC 1.9 2.6 3.8 5.4 6.6 9 12
Continuous kVA 690 V AC 1.9 2.6 3.8 5.4 6.6 9 12
Max. input current
Continuous (3x525–550 V) [A] 1.9 2.4 3.5 4.4 5.5 8 10
Intermittent (3x525–550 V) [A] 2.1 2.6 3.8 8.4 6.0 8.8 11
Continuous kVA (3x551–690 V) [A] 1.4 2.0 2.9 4.0 4.9 6.7 9
Intermittent kVA (3x551–690 V) [A] 1.5 2.2 3.2 4.4 5.4 7.4 9.9
Additional specifications
IP20 max. cable cross-section
5)
(line power,
motor, brake and load sharing) [mm
2
]/(AWG)
[0.2–4]/(24–10)
Estimated power loss at rated max. load [W]
4)
44 60 88 120 160 220 300
Weight, enclosure IP20 (lbs [kg]) 14.55 [6.6] 14.55 [6.6] 14.55 [6.6] 14.55 [6.6] 14.55 [6.6] 14.55 [6.6] 14.55 [6.6]
Efficiency
4)
0.96 0.96 0.96 0.96 0.96 0.96 0.96
Table 10.9 Line Power Supply 3 x 525–690 V AC IP20
Specifications
VLT
®
AQUA Drive
Instruction Manual
MG20M922 - VLT
®
is a registered Danfoss trademark 10-9
