Max. terminal load (AC-15)
1)
on 4-5 (NO) (Inductive load @ cosφ 0.4) 240 V AC, 0.2 A
Max. terminal load (DC-1)
1)
on 4-5 (NO) (Resistive load) 80 V DC, 2 A
Max. terminal load (DC-13)
1)
on 4-5 (NO) (Inductive load) 24 V DC, 0.1 A
Max. terminal load (AC-1)
1)
on 4-6 (NC) (Resistive load) 240 V AC, 2 A
Max. terminal load (AC-15)
1)
on 4-6 (NC) (Inductive load @ cosφ 0.4) 240 V AC, 0.2 A
Max. terminal load (DC-1)
1)
on 4-6 (NC) (Resistive load) 50 V DC, 2 A
Max. terminal load (DC-13)
1)
on 4-6 (NC) (Inductive load) 24 V DC, 0.1 A
Min. terminal load on 1-3 (NC), 1-2 (NO), 4-6 (NC), 4-5 (NO) 24 V DC 10 mA, 24 V AC 20 mA
Environment according to EN 60664-1 overvoltage category III/pollution degree 2
1) IEC 60947 parts 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
2) Overvoltage Category II
3) UL applications 300 V AC 2 A
Control card, 10 V DC output
Terminal number 50
Output voltage 10.5 V ±0.5 V
Max. load 25 mA
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control characteristics
Resolution of output frequency at 0–1000 Hz ±0.003 Hz
System response time (terminals 18, 19, 27, 29, 32, 33) ≤ 2 ms
Speed control range (open-loop) 1:100 of synchronous speed
Speed accuracy (open-loop) 30-4,000 rpm: Maximum error of ±8 rpm
All control characteristics are based on a 4-pole asynchronous motor
Surroundings
Enclosure type A IP20/Chassis, IP21 kit/Type 1, IP55/Type12, IP66
Enclosure type B1/B2 IP21/Type 1, IP55/Type12, IP66
Enclosure type B3/B4 IP20/Chassis
Enclosure type C1/C2 IP21/Type 1, IP55/Type 12, IP66
Enclosure type C3/C4 IP20/Chassis
Enclosure type D1/D2/E1 IP21/Type 1, IP54/Type12
Enclosure type D3/D4/E2 IP00/Chassis
Enclosure kit available ≤ enclosure type A IP21/TYPE 1/IP4X top
Vibration test enclosure A/B/C 0.035 oz [1.0 g]
Vibration test enclosure D/E/F 0.024 oz [0.7 g]
Max. relative humidity 5%–95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 721-3-3), uncoated class 3C2
Aggressive environment (IEC 721-3-3), coated class 3C3
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature Max. 122 °F [50 °C]
Derating for high ambient temperature, see section on special conditions
Minimum ambient temperature during full-scale operation 32 °F [0 °C]
Minimum ambient temperature at reduced performance 14 °F [-10 °C]
Temperature during storage/transport -13 to +149/158 °F [-25 to +65/70 °C]
Maximum altitude above sea level without derating 3300 ft [1000 m]
Maximum altitude above sea level with derating 10,000 ft [3000 m]
Derating for high altitude, see section on special conditions
EMC standards, Emission EN 61800-3, EN 61000-6-3, EN 55011, IEC 61800-3
EMC standards, Immunity EN 61800-3, EN 61000-6-1/2,
Specifications
VLT
®
AQUA Drive
Instruction Manual
MG20M922 - VLT
®
is a registered Danfoss trademark 10-15
