Danfoss VLT AQUA Drive FC 202 Instruction Manual

Enclosure Power (hp [kW]) Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Moeller
Max trip level [A]
A1 - gG-10 gG-25 PKZM0-16 16
A2 1.5–5 [1.1–4.0] gG-10 (0.5–4 [0.37–3])
gG-16 (5 [4])
gG-25 PKZM0-25 25
A3 7.5–10 [5.5–7.5] gG-16 gG-32 PKZM0-25 25
A4 1.5–5 [1.1–4.0] gG-10 (0.5–4 [0.37–3])
gG-16 (5 [4])
gG-32 PKZM0-25 25
A5 1.5–10 [1.1–7.5] gG-10 (0.5–4 [0.37–3])
gG-16 (5–10 [4–7.5])
gG-32 PKZM0-25 25
B1 15–25 [11–18.5] gG-40 gG-80 PKZM4-63 63
B2 30–40 [22–30] gG-50 (25 [18.5])
gG-63 (30 [22])
gG-100 NZMB1-A100 100
B3 15–25 [11–18] gG-40 gG-63 PKZM4-50 50
B4 30–50 [22–37] gG-50 (25 [18.5])
gG-63 (30 [22])
gG-80 (40 [30])
gG-125 NZMB1-A100 100
C1 50–75 [37–55] gG-80 (40 [30])
gG-100 (50 [37])
gG-160 (60 [45])
gG-160 NZMB2-A200 160
C2 100–125 [75–90] aR-200 (75 [55])
aR-250 (100 [75])
aR-250 NZMB2-A250 250
C3 60–75 [45–55] gG-100 (50 [37])
gG-160 (60 [45])
gG-150 (50 [37])
gG-160 (60 [45])
NZMB2-A200 150
C4 100–125 [75–90] aR-200 (75 [55])
aR-250 (100 [75])
aR-250 NZMB2-A250 250
Table 10.13 380–480 V, Frame Sizes A, B and C
Specifications
VLT
®
AQUA Drive
Instruction Manual
