Enclosure Power (hp [kW]) Recommended fuse size Recommended max. fuse Recommended circuit
breaker
Danfoss
Max trip level[A]
A3
1.5 [1.1] gG-6 gG-25 CTI25M 10-16 16
2 [1.5] gG-6 gG-25 CTI25M 10-16 16
3 [2.2] gG-6 gG-25 CTI25M 10-16 16
4 [3] gG-10 gG-25 CTI25M 10-16 16
5 [4] gG-10 gG-25 CTI25M 10-16 16
7.5 [5.5] gG-16 gG-25 CTI25M 10-16 16
10 [7.5] gG-16 gG-25 CTI25M 10-16 16
B2
15 [11] gG-25 gG-63
20 [15] gG-25 gG-63
25 [18] gG-32
30 [22] gG-32
C2
40 [30] gG-40
50 [37] gG-63 gG-80
60 [45] gG-63 gG-100
75 [55] gG-80 gG-125
100 [75] gG-100 gG-160
C3
50 [37] gG-100 gG-125
60 [45] gG-125 gG-160
D
50 [37] gG-125 gG-125
60 [45] gG-160 gG-160
75–100 [55–75] gG-200 gG-200
125 [90] aR-250 aR-250
Table 10.15 525–690 V, Frame Sizes A, C and D (non-UL fuses)
Specifications
VLT
®
AQUA Drive
Instruction Manual
10-20 MG20M922 - VLT
®
is a registered Danfoss trademark
