9.3.8 AF Settings 300-**

NOTICE!

Except for parameter 300-10 Active Filter Nominal Voltage, it is not recommended to change the settings in this par.

group for the Low Harmonic Drive

Par. No. # Parameter description Default value 4-set-up Change

during

operation

Conver-

sion index

Type

300-0* General Settings

300-00 Harmonic Cancellation Mode [0] Overall All set-ups TRUE - Uint8

300-01 Compensation Priority [0] Harmonics All set-ups TRUE - Uint8

300-1* Network Settings

300-10 Active Filter Nominal Voltage ExpressionLimit 2 set-ups FALSE 0 Uint32

300-2* CT Settings

300-20 CT Primary Rating ExpressionLimit 2 set-ups FALSE 0 Uint32

300-22 CT Nominal Voltage 342 V 2 set-ups FALSE 0 Uint32

300-24 CT Sequence [0] L1, L2, L3 2 set-ups FALSE - Uint8

300-25 CT Polarity [0] Normal 2 set-ups FALSE - Uint8

300-26 CT Placement [1] Load Current 2 set-ups FALSE - Uint8

300-29 Start Auto CT Detection [0] O All set-ups FALSE - Uint8

300-3* Compensation

300-30 Compensation Points 0.0 A All set-ups TRUE -1 Uint32

300-35 Cos-phi Reference 0.500 N/A All set-ups TRUE -3 Uint16

300-4* Paralleling

300-40 Master Follower Selection [2] Not Paralleled 2 set-ups FALSE - Uint8

300-41 Follower ID 1 N/A 2 set-ups FALSE 0 Uint32

300-42 Num. of Follower AFs 1 N/A 2 set-ups FALSE 0 Uint32

300-5* Sleep Mode

300-50 Enable Sleep Mode null 2 set-ups TRUE - Uint8

300-51 Sleep Mode Trig Source [0] Line power All set-ups TRUE - Uint8

300-52 Sleep Mode Wake-up Trigger ExpressionLimit All set-ups TRUE 0 Uint32

300-53 Sleep Mode Sleep Trigger 80% All set-ups TRUE 0 Uint32

Appendix A - Parameters

VLT

AQUA Drive FC 202 Low Harmonic Drive
