Danfoss VLT AQUA Drive FC 202 Installation Manual

130BD571.11
1
6
7
8
9
11
13
15
16
20
21
22
2
3
4
5
10
12
14
18
19
17
1 Local control panel (LCP) 13 Electrical fuses
2 Active lter card (AFC) 14 Line power disconnect
3 Metal oxide varistor (MOV) 15 Line Power Terminals
4 Soft-charge resistors 16 Heatsink fan
5 AC capacitors discharge board 17 DC capacitor bank
6 Line power contactor 18 Current transformer
7 LC inductor 19 RFI dierential mode lter
8 AC capacitors 20 RFI common mode lter
9 Line power bus bars to drive input 21 HI inductor
10 IGBT fuses 22 Power card
11 RFI
Figure 1.3 Frame Size D13 Filter Enclosure
Introduction
VLT
®
AQUA Drive FC 202 Low Harmonic Drive
8 Danfoss A/S © 10/2015 All rights reserved. MG21B322
