1 Contactor 4 Circuit breaker or disconnect (if purchased)
2 RFI lter 5 AC line power/line fuses (if purchased)
3 Line power AC power input terminals
Figure 1.6 Frame Size F18 Options Cabinet
*The options cabinet is not optional for the LHD. The ancillary equipment is stored in the cabinet.
Introduction Installation Manual
MG21B322 Danfoss A/S © 10/2015 All rights reserved. 11
1 1
