Danfoss VLT AQUA Drive FC 202 Installation Manual

when dealing with harmonic limits containing low harmonic numbers, the IEEE 519 limits are lower than the 61000-2-4
limits. Low harmonic drives observe the total harmonic distortion as dened in IEEE 519 for all R
sce
. Each individual
harmonic current fullls table 10-3 in IEEE 519 for R
sce
≥20.
I
SC
/I
L
(R
SCE
) h<11 11≤h<17 17≤h<23 23≤h<35 35≤h Total demand
distortion TDD
<20 4% 2.0% 1.5% 0.6% 0.3% 5%
20<50 7% 3.5% 2.5% 1.0% 0.5% 8%
50<100 10% 4.5% 4.0% 1.5% 0.7% 12%
100<1000 12% 5.5% 5.0% 2.0% 1.0% 15%
>1000 15% 7.0% 6.0% 2.5% 1.4% 20%
Table 1.11 Permissible Harmonic Currents at the PCC
The VLT
®
AQUA Drive FC 202 Low Harmonic Drive complies with the following standards:
•
IEC61000-2-4
•
IEC61000-3-4
•
IEEE 519
•
G5/4
Introduction Installation Manual
MG21B322 Danfoss A/S © 10/2015 All rights reserved. 19
1 1
