Danfoss VLT AQUA Drive FC 202

130BE113.10
64.5
[2.5]
560.0
[22.0]
422.4
[16.6]
384.8
[15.1]
18.6
[0.7]
27.5
[1.1]
227.8
[9.0]
220.0
[8.7]
235.0
[9.3]
40.4
[1.6]
8X 25.0
[1.0]
8X 14.0
[0.6]
330.0
[13.0]
470.4
[18.5]
390.0
[15.4]
246.0
[9.7]
1
1 Cable entry locations
Figure 3.10 Cable Entry Diagram, Enclsoure Size D2n
Mechanical Installation
VLT
®
AQUA Drive FC 202 Low Harmonic Drive
