RCD
Residual Current Device.
Set-up
You can save parameter settings in four set-ups. Change between the four parameter set-ups, and edit one set-up, while another set-up is active.
SFAVM
Switching pattern called
S tator F lux oriented A synchronous V ector M odulation (par. 14-00).
Slip Compensation
The adjustable frequency drive compensates for the motor slip by giving the frequency a supplement that follows the measured motor load keeping the
motor speed almost constant..
Smart Logic Control (SLC)
The SLC is a sequence of user-defined actions executed when the associated user-defined events are evaluated as true by the SLC.
Thermistor:
A temperature-dependent resistor placed where the temperature is to be monitored (adjustable frequency drive or motor).
Trip
A state entered in fault situations, e.g., if the adjustable frequency drive is subject to an overtemperature or when the adjustable frequency drive is
protecting the motor, process or mechanism. Restart is prevented until the cause of the fault has disappeared and the trip state is canceled by activating
reset or, in some cases, by being programmed to reset automatically. Trip may not be used for personal safety.
Trip Locked
A state entered in fault situations when the adjustable frequency drive is protecting itself and requiring physical intervention, e.g., if the adjustable
frequency drive is subject to a short circuit on the output. A locked trip can only be canceled by cutting off line power, removing the cause of the fault,
and reconnecting the adjustable frequency drive. Restart is prevented until the trip state is canceled by activating reset or, in some cases, by being
programmed to reset automatically. The trip-lock function may not be used as a personal safety measure.
VT Characteristics
Variable torque characteristics used for pumps and fans.
VVC
plus
If compared with standard voltage/frequency ratio control, Voltage Vector Control (VVC
plus
) improves the dynamics and the stability, both when the speed
reference is changed and in relation to the load torque.
60° AVM
Switching pattern called 60°
A synchronous V ector M odulation (par. 14-00).
VLT
®
AQUA Drive Design Guide 1 How to Read this Design Guide
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 1-7
1

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
