Danfoss vlt aqua Design Guide

4.2 Ordering Numbers
4.2.1 Ordering Numbers: Options and Accessories
Type Description Ordering no.
Miscellaneous hardware
DC link connector Terminal block for DC link connection, frame size A2/A3 130B1064
IP 21/4X top/TYPE 1 kit Enclosure, frame size A2: IP21/IP 4X Top/TYPE 1 130B1122
IP 21/4X top/TYPE 1 kit Enclosure, frame size A3: IP21/IP 4X Top/TYPE 1 130B1123
IP21/TYPE 1 Kit Top and bottom, frame size B3 130B1187
IP21/TYPE 1 Kit Top and bottom, frame size B4 130B1189
IP21/TYPE 1 Kit Top and bottom, frame size C3 130B1191
IP21/TYPE 1 Kit Top and bottom, frame size C4 130B1193
IP21/TYPE 1 Kit Top, frame size B3 130B1188
IP21/TYPE 1 Kit Top, frame size B4 130B1190
IP21/TYPE 1 Kit Top, frame size C3 130B1192
IP21/TYPE 1 Kit Top, frame size C4 130B1194
MCF 110 panel Panel Through Mounting Kit, frame size A5 130B1028
MCF 110 panel Panel Through Mounting Kit, frame size B1 130B1046
MCF 110 panel Panel Through Mounting Kit, frame size B2 130B1047
MCF 110 panel Panel Through Mounting Kit, frame size C1 130B1048
MCF 110 panel Panel Through Mounting Kit, frame size C2 130B1049
Profibus D-Sub 9 Connector kit for IP 20 130B1112
MCF 103 USB Cable 14 in [350 mm], IP55/66 130B1155
MCF 103 USB Cable 26 in [650 mm], IP55/66 130B1156
Profibus top entry kit Top entry kit for Profibus connection - only A enclosures
130B0524
1)
Terminal blocks Screw terminal blocks for replacing spring loaded terminals
1 x 10-pin, 1 x 6-pin and 1 x 3-pin connectors 130B1116
Backplate IP21 / NEMA 1 enclosure Top Cover A2 130B1132
Backplate IP21 / NEMA 1 enclosure Top Cover A3 130B1133
Backplate A5, IP55 / NEMA 12 130B1098
Backplate B1, IP21 / IP55 / NEMA 12 130B3383
Backplate B2, IP21 / IP55 / NEMA 12 130B3397
Backplate C1, IP21 / IP55 / NEMA 12 130B3910
Backplate C2, IP21 / IP55 / NEMA 12 130B3911
Backplate A5, IP66 / NEMA 4x 130B3242
Backplate B1, IP66 / NEMA 4x 130B3434
Backplate B2, IP66 / NEMA 4x 130B3465
Backplate C1, IP66 / NEMA 4x 130B3468
Backplate C2, IP66 / NEMA 4x 130B3491
LCP
LCP 101 Numerical Local Control Panel (NLCP) 130B1124
LCP 102 Graphical Local Control Panel (GLCP) 130B1107
LCP cable Separate LCP cable, 9.8 ft. [3 m] 175Z0929
LCP kit Panel mounting kit including graphical LCP, fasteners, 9.8 ft. [3 m] cable
and gasket
130B1113
LCP kit Panel mounting kit including numerical LCP, fasteners and gasket 130B1114
LCP kit Panel mounting kit for all LCPs including fasteners, 9.8 ft. [3 m] cable and
gasket
130B1117
LCP kit Panel mounting kit for all LCPs including fasteners and gasket - without ca-
ble
130B1170
LCP kit Panel mounting kit for all LCPs including fasteners, 26 ft [8 m] cable, con-
nectors and gasket for IP55/66 enclosures
130B1129
4 How to Order VLT
®
AQUA Drive Design Guide
4-6 MG.20.N5.22 - VLT
®
is a registered Danfoss trademark
4

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
