Danfoss vlt aqua Design Guide

Adjustable frequency drive: Max. fuse size: Voltage: Type:
200–240 V
K25-K75
10A
1
200–240 V type gG
1K1-2K2
20A
1
200–240 V type gG
3K0
30A
1
200–240 V type gG
3K7
30A
1
200–240 V type gG
5K5
50A
1
200–240 V type gG
7K5
63A
1
200–240 V type gG
11K
63A
1
200–240 V type gG
15K
80A
1
200–240 V type gG
18K5
125A
1
200–240 V type gG
22K
125A
1
200–240 V type gG
30K
160A
1
200–240 V type gG
37K
200A
1
200–240 V type aR
45K
250A
1
200–240 V type aR
380–480 V
K37-1K5
10A
1
380–480 V type gG
2K2-4K0
20A
1
380–480 V type gG
5K5-7K5
30A
1
380–480 V type gG
11K
63A
1
380–480 V type gG
15K
63A
1
380–480 V type gG
18K
63A
1
380–480 V type gG
22K
63A
1
380–480 V type gG
30K
80A
1
380–480 V type gG
37K
100A
1
380–480 V type gG
45K
125A
1
380–480 V type gG
55K
160A
1
380–480 V type gG
75K
250A
1
380–480 V type aR
90K
250A
1
380–480 V type aR
Table 5.4: Non-UL fuses 200 V to 480 V
1) Max. fuses - see national/international regulations to select an appropriate fuse size.
Danfoss PN Bussmann Ferraz Siba
20220 170M4017 6.9URD31D08A0700 20 610 32.700
20221 170M6013 6.9URD33D08A0900 20 630 32.900
Table 5.5: Additional Fuses for Non-UL Applications, E enclosures, 380-480 V
VLT
®
AQUA Drive Design Guide 5 How to Install
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 5-21
5

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
