Figure 5.27: Position of ground terminals IP00, frame sizes
D
Figure 5.28: Position of ground terminals IP21 (NEMA type
1) and IP54 (NEMA type 12)
NOTE!
D2 and D4 shown as examples. D1 and D3 are equivalent.
